Dump Bodies

Aluminum Magnum Dump

Aluminum Magnum Dump


  • Available lengths 8’10”, 9’8”, 10’6”, and 11’4” X 96” Wide
  • No crossmembers for low mounting height
  • 6” aluminum channel long sills
  • 1 ¼” extruded aluminum floor with 6.85 extruded aluminum side rails
  • 42” standard tapered bulkhead with integrated punched window
  • 12” double wall rigid sides with 6” board pocket extensions
  • ¼” thick boxed rear corners
  • Lever activated cam locks for easy folding
  • 23” double wall (3/16”), dual acting tailgate with single lever center release
  • Heavy oil lite bronze bushings located at the tailgate pivot points
  • Cab trip handle for spreading
  • Lighting and marking to FMVSS #108 Standards
  • LED body marker lights



Options:

  • Scott level-lift hoist package
  • 12” cab shield
  • Bulkhead light package
  • Underbody toolboxes
