SCOTT Level Lift LL-2500

Twin Telescopic Hinge Back

Large Truck Applications - 18'-24' Bodies - Class K

• *10 3/16" Mounting Height (minimum) - Mounts with 11" & Larger Long Sills
• *Pump Set at 3500 PSI (pump options) * Cylinder three moving stages & Chrome Shaft * Stroke 80 1/4"
• *Approximate Weight 804 lbs. plus 50 quarts of oil

LL-2500 Mounting and Capacity Chart Measured in Tons - 3500 PSI

Note:   (Use hoist calculator to estimate capacity)

>> HOIST CALCULATOR CLICK HERE <<

1. Option for single or double valve operation.
2. Controlled by air or pull cable.
3. Overhang based upon 55" from center line of tail hinge pin to center line of truck trunnion, with 2" clearance between cab and body.
4. Capacities (Tons) are for a water level load including body weight plus payload weight, and assume payload to be centered in body front to back
5. Chart does not cover all mounting conditions. Call Tafco @ 507-526-3247

(* electric pumps decrease capacity by approximately 10%)

*Overhang is based upon 34 inches loaded frame height. (36 inch loaded frame height shown in parenthesis)
